Quarry Stone Cutting Machine China
Quarry Stone Cutting Machine China
Brief Introduction:
Quarry stone cutting machine is designed according to the impact principle to crush stuff.Actually it is a new high-efficiency crusher,which is improved on the basis of hammer crusher.quarry stone cutting machine can be used to crush limestone,asbestos ore, coal, quartz sand, calcium carbide, dolomite, iron sulfide ore and so on. It can be applied to coarse crushing,medium crushing or fine crushing.
Now our PF series quarry stone cutting machine can meet the requirements for both output size and capacity,especially for aggregate gradation of asphalt concrete on skid-resistant surface in high-grade road, as well as the requested capacity above 100T/H to process hard stone such as basalt,andesite.
Quarry stone cutting machine is a crushing machine that use impact energy to crush stuff. On the part of mechanical energy application, machines using impact energy is superior to machinces using static pressure to crush stuff by extrusion.
Jaw Crusher is basically used to crush stuff by extrusion,while quarry stone cutting machine is used to crush stuff by impact energy,which belongs to high-energy crusher.
Quarry Stone Cutting Machine Performance Characteristics:
1, the feed opening large, high crushing chamber to adapt to high material hardness, block degree, the product powder less;
2, counterattack plate and plate hammer clearance can be easily adjusted, effective control of feed size, particle shape;
3, the compact structure, the machine rigidity, the rotor having a large moment of inertia;
4, high chrome plate hammer, impact, abrasion resistance, impact;
5, keyless connection, easy maintenance, economical and reliable;
6, crushing function full, high productivity, mechanical wear, comprehensive benefits.
Quarry Stone Cutting Machine Fault Maintenance:
1, Abnormal vibration.
Reasons: 1) the material is too large; 2) board hammer uneven wear; 3) rotor imbalance; 4, the basis of improper handling.
Remedy: 1) you can check the feed size; 2) replace the counterattack hammer; 3) adjustment of the rotor; 4) Check anchor bolts and reinforcement.
2, The material is too large.
Reasons: due to excessive wear and tear the liner or board hammer, causing the gap is too large.
Remedy: counterattack frame gap before and after adjustment or replacement of the liner plate hammer.
3, The machine internally generated percussion.
Reasons: 1) the material into the inside of the machine can not be broken; 2) liner fasteners relaxation, the the plate hammer impact liner; 3) plate hammer or other parts of the fracture.
Remedy: Check the body, foreign body removal, fastening lining or replacement parts.
4, Bearing temperature is too high.
Reasons: 1) too much grease or inadequate; 2) Grease dirty; 3) bearing damage.
Remedy: 1) Check whether the right amount of grease; 2) replaced after cleaning the bearing grease; 3) replace the bearings.
Quarry Stone Cutting Machine Working Principle:
Quarry stone cutting machine is a rebound effect of the high-speed impact of the board hammer and counterattack plate, so that the material by repeated shocks broken machinery, the main structure: rack rotor plate hammer, counterattack plate, side guard plate.
Work, driven by the motor, the rotor high-speed rotation and materials into the active area of the plate hammer, quarry stone cutting machine plate hammer on the rotor, and later was thrown to the the counterattack device again broken counterattack board bounce ore and then with the other ores thrown in the back of the board hammer or rotor collide with each other, therefore, in the first crushing chamber ore was crushed by repeated shocks. Some ore broken in the first crushing chamber to a certain size, after a counterattack the gap between the plate and the rotor row to the second crushing chamber, continue to be repeated strikes, until it reaches the ideal particle size only by the bottom row of ore crusher discharge port .
Liming Quarry Stone Cutting Machine China:
Liming Heavy Industry is committed to producing the best mechanical crushing equipment, capable of producing various types of crusher and mill, and reached the leading level in the world. We are a trustworthy quarry stone cutting machine manufacturer capable of producing all types of quarry stone cutting machine, good quality and reasonable prices. Liming Heavy Industry production of quarry stone cutting machine is a set of similar products at home and abroad, the successful experience, devote themselves to come up with an energy-efficient crushing equipment. Medium-sized quarry stone cutting machine is one of the leading products of the company, especially in the design and production of large crusher mill at the absolute leading level at home and abroad.
If you need any help of quarry stone cutting machine China, please contact us directly. We aim to provide you with the best quarry stone cutting machine and the most economical reasonable solution, our experts will provide technical assistance at any time for you. Looking forwards to establish a long-term business relationship with you.
